Transient Activation Encapsulation Enables Separation-Free Production of High-Purity 177Lu in the G.A. Siwabessy Medium-Flux Research Reactor

Maskur Maskur; Yono Sugiharto; Endang Sarmini; Fransiska Christydira Sekaringtyas; Sulaiman; Aulia Arivin Billah; Lira Aprilia Pujianti; Fani Triyatna; Rien Ritawidya; Muhammad Ridwan

doi:10.55981/urania.2026.13640

Authors

Maskur Maskur Research Center for Radioisotope, Radiopharmaceuticals, and Biodosimetry Technology BRI
Yono Sugiharto Directorate of Nuclear Facility Management BRIN
Endang Sarmini Directorate of Nuclear Facility Management BRIN
Fransiska Christydira Sekaringtyas Research Center for Radioisotope, Radiopharmaceuticals, and Biodosimetry Technology BRI
Sulaiman Research Center for Radioisotope, Radiopharmaceuticals, and Biodosimetry Technology BRI
Aulia Arivin Billah Research Center for Radioisotope, Radiopharmaceuticals, and Biodosimetry Technology BRI
Lira Aprilia Pujianti Directorate of Nuclear Facility Management BRIN
Fani Triyatna Directorate of Nuclear Facility Management BRIN
Rien Ritawidya Research Center for Radioisotope, Radiopharmaceuticals, and Biodosimetry Technology BRI
Muhammad Ridwan Department of Chemistry, Faculty of Mathematics and Natural Sciences, Universitas Indonesia

DOI:

https://doi.org/10.55981/urania.2026.13640

Keywords:

Lutetium-177, direct production, encapsulation, radionuclidic purity, separation-free

Abstract

The production of high-purity ¹⁷⁷Lu via the direct (n,γ) route is highly dependent not only on isotopic enrichment of the target material but also on the strategic selection of encapsulation materials to reduce radionuclidic impurities. In order to optimize the production of high-specific-activity ¹⁷⁷LuCl₃, this work combines a double-layer containment system consisting of quartz ampoules (SiO₂) and high-purity aluminum capsules (Al 1070) with an enriched Lu₂O₃target (74% ¹⁷⁶Lu). Irradiation was performed in the RSG-GA Siwabessy reactor (BRIN, Indonesia) at a thermal neutron flux of 2 × 10¹⁴ n·cm⁻²·s⁻¹ for 99 and 193 hours. The target was dissolved in HCl/H₂O₂to form ¹⁷⁷LuCl₃and then characterized for radionuclidic purity using high-resolution gamma spectrometry (HPGe) at 48 hours post-end of irradiation (EOI). The results exhibit that this integrated system produces products without detectable container-derived radionuclidic impurities at 48 h post-EOI: activation products from the quartz (¹⁹O, T½ = 26.47s; ³¹Si, T½ = 2.62 h) and aluminum (²⁸Al, T½ = 2.24 min) containers decayed completely within 24 hours. Under normal HPGe conditions, the metastable isomer ¹⁷⁷ᵐLu (T½ = 160.4 d, σ = 2.85 barn), the sole co-produced radionuclidic species, is present at <1% of total activity at EOI, is not detected spectroscopically from initial state of ¹⁷⁷Lu, which can be clinically negligible during the typical therapeutic window (1–14 days post-production). The specific activity obtained was 11 718 mCi/mg (CV = 5.9%) after 193 hours of irradiation, a level adequate for effective radiolabeling of monoclonal antibodies and peptides in targeted radionuclide therapy, despite the presence of stable Lu carrier. This study demonstrates that the interaction between target chemistry and container physics, rather than irradiation parameters alone, is a critical determinant in producing pharmaceutical-grade ¹⁷⁷Lu that meets international radionuclidic purity standards (>99.9%). This approach provides a scalable, separation-free production model applicable to medium-flux research reactors globally.

References

[1]. S. C. George and E. J. J. Samuel, "Developments in 177Lu-based radiopharmaceutical therapy and dosimetry," Frontiers in Chemistry, vol. 11, pp. 1-13, 2023.

https://doi.org/10.3389/fchem.2023.1218670

[2]. K. Chakraborty, J. Mondal, J. M. An, J. Park, and Y.-K. Lee, "Advances in radionuclides and radiolabelled peptides for cancer therapeutics," Pharmaceutics, vol. 15, p. 971, 2023.

https://doi.org/10.3390/pharmaceutics15030971

[3]. A. Gafita et al., "RECIP 1.0 predicts progression-free survival after [177Lu]Lu-PSMA radiopharmaceutical therapy in patients with metastatic castration-resistant prostate cancer," Journal of Nuclear Medicine, vol. 65, pp. 917-922, 2024.

https://doi.org/10.2967/jnumed.123.267234

[4]. J. Gawel and Z. Rogulski, "The challenge of single-photon emission computed tomography image segmentation in the internal dosimetry of 177Lu molecular therapies," Journal of Imaging, vol. 10, pp. 1-23, 2024.

https://doi.org/10.3390/jimaging10010027

[5]. K. Sjögreen et al., "EANM dosimetry committee recommendations for dosimetry of 177Lu-labelled somatostatin-receptor-and PSMA-targeting ligands," European Journal of Nuclear Medicine and Molecular Imaging, vol. 49, pp. 1778-1809, 2022.

https://doi.org/10.1007/s00259-022-05727-7

[6]. J. A. Korsen et al., "Neuroendocrine prostate cancer," Proceedings of the National Academy of Sciences, vol. 119, pp. 1-7, 2022.

https://doi.org/10.1073/pnas.2203820119

[7]. S. J. Keam, "Lutetium Lu 177 vipivotide tetraxetan: First approval," Molecular Diagnosis & Therapy, vol. 26, pp. 469-477, 2022.

https://doi.org/10.1007/s40291-022-00594-2

[8]. T. Ladrière et al., "Safety and therapeutic optimization of lutetium-177 based radiopharmaceuticals," Pharmaceutics, vol. 15, pp. 1-19, 2023.

https://doi.org/10.3390/pharmaceutics15041240

[9]. P. E. Harris, K. Zhernosekov, and A. Harris, "The evolution of PRRT for the treatment of neuroendocrine tumors: What comes next?" Frontiers, vol. 13, pp. 1-9, 2022.

https://doi.org/10.3389/fendo.2022.941832

[10]. U. Hennrich, "Lutathera®: The first FDA-and EMA-approved radiopharmaceutical for peptide receptor radionuclide therapy," Pharmaceuticals, vol. 12, pp. 1-8, 2019.

https://doi.org/10.3390/ph12030114

[11]. U. Hennrich and M. Eder, "[177Lu]Lu-PSMA-617 (Pluvicto™): The first FDA-approved radiotherapeutical for treatment of prostate cancer," Pharmaceuticals, vol. 15, pp. 1-13, 2022.

https://doi.org/10.3390/ph15101292

[12]. B.-N. Park et al., "177Lu anti-angiogenic radioimmunotherapy targeting ATP synthase in gastric cancer model," Antibodies, vol. 13, p. 51, 2024.

https://doi.org/10.3390/antib13030051

[13]. K. Shim et al., "Cure of disseminated human lymphoma with [177Lu]Lu-ofatumumab in a preclinical model," Journal of Nuclear Medicine, vol. 64, pp. 542-548, 2023.

https://doi.org/10.2967/jnumed.122.264816

[14]. A. Y. Jia et al., "Lutetium-177 DOTATATE: A practical review," Practical Radiation Oncology, vol. 12, pp. 305-311, 2022.

https://doi.org/10.1016/j.prro.2022.02.002

[15]. S. Sharma and M. K. Pandey, "Radiometals in imaging and therapy: Highlighting two decades of research," Pharmaceutical Journal, vol. 1460, pp. 1-44, 2023.

https://doi.org/10.3390/ph16101460

[16]. K. Herman et al., "Set up a theranostics center," Journal of Nuclear Medicine, vol. 63, pp. 1836-1843, 2022.

https://doi.org/10.2967/jnumed.122.264321

[17]. R. Garje, T. A. Hope, R. B. Rumble, and R. A. Parikh, "Systemic therapy update on 177Lu-PSMA-617 for metastatic castration-resistant prostate cancer: ASCO guideline rapid recommendation Q and A," JCO Oncology Practice, vol. 19, pp. 132-135, 2023.

https://doi.org/10.1200/OP.22.00753

[18]. J. Fallah et al., "FDA approval summary: Lutetium Lu 177 vipivotide tetraxetan for patients with metastatic castration-resistant prostate cancer," Clinical Cancer Research, vol. 29, pp. 1651-1657, 2023.

https://doi.org/10.1158/1078-0432.CCR-22-2875

[19]. S. W. Ling et al., "Advances in 177Lu-PSMA and 225Ac-PSMA radionuclide therapy for metastatic castration-resistant prostate cancer," Pharmaceutical Journal, vol. 14, pp. 1-17, 2022.

https://doi.org/10.3390/pharmaceutics14102166

[20]. L. Shao, "Optimization of deuteron irradiation of 176Yb for producing 177Lu of high specific activity exceeding 3000 GBq/mg," Molecules, vol. 28, pp. 1-22, 2023.

https://doi.org/10.3390/molecules28166053

[21]. S. Patra et al., "Electrochemical separation and purification of no-carrier-added 177Lu for radiopharmaceutical preparation: Translation from bench to bed," Chemical Engineering Journal Advances, vol. 14, p. 100444, 2023.

https://doi.org/10.1016/j.ceja.2023.100444

[22]. M. Balzer et al., "Evaluation of the 177mLu concentration in in-house produced 177Lu-radiopharmaceuticals and commercially available Lutathera®," EJNMMI Radiopharmacy and Chemistry, vol. 8, 2023.

https://doi.org/10.1186/s41181-023-00222-2

[23]. A. Dash, M. R. A. Pillai, and F. F. Knapp, "Production of 177Lu for targeted radionuclide therapy: Available options," Nuclear Medicine and Molecular Imaging, vol. 49, pp. 85-107, 2015.

https://doi.org/10.1007/s13139-014-0315-z

[24]. D. Sairanbayev et al., "Analysis of lutetium-177 production at the WWR-K research reactor," Applied Radiation and Isotopes, vol. 169, p. 109561, 2021.

https://doi.org/10.1016/j.apradiso.2020.109561

[25]. K. Tomiyoshi et al., "Optimization processes of clinical chelation-based radiopharmaceuticals for pathway-directed targeted radionuclide therapy in oncology," Pharmaceuticals, vol. 16, pp. 1-18, 2024.

https://doi.org/10.3390/pharmaceutics16111458

[26]. M. Lin et al., "Monoclonal antibody based radiopharmaceuticals for imaging and therapy," Current Problems in Cancer, vol. 45, p. 100796, 2021.

https://doi.org/10.1016/j.currproblcancer.2021.100796

[27]. V. S. Le, "Specific radioactivity of neutron induced radioisotopes: Assessment methods and application for medically useful," Molecules, vol. 16, pp. 818-846, 2011.

https://doi.org/10.3390/molecules16010818

[28]. R. A. Kuznetsov et al., "Production of lutetium-177: Process aspects," Radiochemistry, vol. 61, pp. 381-395, 2019.

https://doi.org/10.1134/S1066362219040015

[29]. S. C. Rubel Chakravarty, "A review of advances in the last decade on target cancer therapy using 177Lu: Focusing on 177Lu produced by the direct neutron activation route," Journal of Nuclear Medicine and Molecular Imaging, vol. 11, pp. 443-475, 2021.

[30]. W. V. Vogel, S. C. van der Marck, and M. W. J. Versleijen, "Challenges and future options for the production of lutetium-177," European Journal of Nuclear Medicine and Molecular Imaging, vol. 48, pp. 2329-2335, 2021.

https://doi.org/10.1007/s00259-021-05392-2

[31]. Z. Talip et al., "A step-by-step guide for the novel radiometal production for medical applications: Case studies," Molecules, vol. 25, pp. 1-29, 2020.

[32]. Y. Nagai et al., "Estimated isotopic compositions of Yb in enriched 176Yb for producing 177Lu with high radionuclide purity," Journal of the Physical Society of Japan, vol. 2022, pp. 1-10.

[33]. K. Kossert et al., "Activity determination and nuclear decay data of 177Lu," Applied Radiation and Isotopes, vol. 70, pp. 2215-2221, 2012.

https://doi.org/10.1016/j.apradiso.2012.02.104

[34]. S. Banerjee, M. R. A. Pillai, and F. F. Knapp, "Lutetium-177 therapeutic radiopharmaceuticals: Linking chemistry, radiochemistry, and practical applications," Chemical Reviews, vol. 115, pp. 2934-2974, 2015.

https://doi.org/10.1021/cr500171e

[35]. M. R. A. Pillai et al., "Production logistics of 177Lu for radionuclide therapy," Applied Radiation and Isotopes, vol. 59, pp. 109-118, 2003.

https://doi.org/10.1016/S0969-8043(03)00158-1

[36]. L. Rosmayani et al., "Simulation of irradiation calculations on lutetium-177 production in RSG-GAS using U3Si2-Al and U9Mo-Al fuels," Jurnal Teknologi Reaktor Nuklir Tri Dasa Mega, vol. 25, p. 45, 2023.

https://doi.org/10.55981/tdm.2023.6793

[37]. Maskur et al., "Development of polyethylene glycol-modified gold nanoparticles for the delivery of lutetium-177 radiopharmaceuticals based on antibodies," Journal of Drug Delivery Science and Technology, vol. 100, p. 106104, 2024.

https://doi.org/10.1016/j.jddst.2024.106104

[38]. M. Bé, V. Chisté, and C. Dulieu, Table of Radionuclides, vol. 2. BIPM, 2004, pp. 106-112.

[39]. Y. Yang et al., "Whole process establishment of carrier-free 177Lu production: From small-scale production to pilot-scale production," Journal of Radioanalytical and Nuclear Chemistry, vol. 332, pp. 4917-4928, 2023.

https://doi.org/10.1007/s10967-023-09210-x
